Features
Bluetooth version: 5.1
Rate limiting: Yes
Band steering: Yes
VLAN support: Yes
Cabling technology: 10/100/1000Base-T(X)
Bluetooth Low Energy (BLE): Yes
Maximum data transfer rate (2.4 GHz): 575 Mbit/s
6 GHz: No
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Wi-Fi Multimedia (WMM)/(WME): Yes
Number of VLAN IDs: 4096
Number of users: 512 user(s)
Fast roaming: Yes
Wi-Fi roaming: Yes
Quality of Service (QoS) support: Yes
MIMO type: Multi User MIMO
Networking standards: IEEE 802.11ax, IEEE 802.1x, IEEE 802.11ac, IEEE 802.3at, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.11h, IEEE 802.11a, IEEE 802.11i, IEEE 802.11b, IEEE 802.1v
5 GHz: Yes
Bluetooth: Yes
Ethernet LAN data rates: 1000, 100 Mbit/s, 10
2.4 GHz: Yes
MIMO: Yes
Design
International Protection (IP) code: IP67
Housing material: Plastic
Placement: Ceiling, Pole, Wall
Product colour: White
Power
Power consumption (max): 15.2 W
Power over Ethernet (PoE): Yes
Security
Service Set Identifier (SSID) features: Multiple SSIDs
Number of SSID supported: 32
Remote Authentication Dial-In User Service (RADIUS): Yes
Security algorithms: AES-GCMP, WEP, MSCHAPv2, EAP-TTLS, WPA2-Enterprise, AES-CCMP, EAP-TLS, WPA3-Enterprise, TKIP, EAP-FAST, PEAP
Operational conditions
Operating temperature (T-T): -30 - 65 °C
Management features
Syslog: Yes
Web-based management: Yes
Weight & dimensions
Antenna height: 19 cm
Antenna depth: 2.3 cm
Antenna width: 2.3 cm
Width: 250 mm
Depth: 200 mm
Height: 80 mm
Packaging data
Package height: 150 mm
Package width: 300 mm
Package depth: 420 mm
Package weight: 2.94 kg
Packaging content
Mounting kit: Yes
Quantity per pack: 1 pc(s)
Quick start guide: Yes
Protocols
Supported network protocols: LLDP, Proxy ARP, LACP, L2TPv3, IPv4, IPv6
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
Antenna
Antennas quantity: 4
Antenna connector type: N-type
Antenna type: External
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Safety warning
Warnings: Electronic products should be recycled at specialist electronic waste collection facilities., Do not expose to prolonged moisture., Avoid direct contact with water.
