Design
Rack mounting: Yes
Housing material: Metal
Number of fans: 2 fan(s)
Form factor: 1U
Product colour: Black
LED indicators: Yes
Power
Power supply included: Yes
Power source: AC
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (max): 35 W
Security
IGMP snooping: Yes
Access Control List (ACL): Yes
SSH/SSL support: Yes
Static port security: Yes
DHCP features: DHCP server
IGMP proxy: Yes
IGMP entries: 1024
Authentication type: IEEE 802.1x, RADIUS, TACACS+
MAC address filtering: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
MIB support: MIB II, Bridge MIB, Interface MIB, SMON MIB, IGMP MIB
Switch type: Managed
Configuring Location Settings (CLI): Yes
System event log: Yes
Switch layer: L2/L3
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 442 mm
Height: 211 mm
Depth: 44 mm
Weight: 2.35 kg
Network
Port mirroring: Yes
Link aggregation: Yes
10G support: Yes
Number of VLANs: 4093
VLAN support: Yes
Flow control support: Yes
Broadcast storm control: Yes
Cable types supported: Cat6, Cat7
Rate limiting: Yes
IP routing: Yes
Virtual LAN features: Voice VLAN
Networking standards: IEEE 802.1w, IEEE 802.3af, IEEE 802.3bt, IEEE 802.1s, IEEE 802.3at, IEEE 802.1D
Packaging data
Package depth: 400 mm
Package height: 100 mm
Package weight: 3.75 kg
Package width: 570 mm
Packaging content
Manual: Yes
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Console port: RJ-45
Power connector: AC-in jack
Gigabit Ethernet (copper) ports quantity: 4
SFP28 ports quantity: 2
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity: 8
2.5G Ethernet (copper) ports quantity: 4
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
MAC address table: 16000 entries
Jumbo frames: 10240
Jumbo frames support: Yes
Static route: Yes
Throughput: 188 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 4
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
