Design
Form factor: 1U
LED indicators: Yes
Product colour: Black
Rack mounting: Yes
Number of fans: 1 fan(s)
Housing material: Metal
Power
Power consumption (max): 865 W
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power supply included: Yes
Power source: AC
Security
MAC address filtering: Yes
IGMP proxy: Yes
Authentication type: IEEE 802.1x, RADIUS, TACACS+
IGMP snooping: Yes
DHCP features: DHCP server
IGMP entries: 1024
Static port security: Yes
SSH/SSL support: Yes
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Heat dissipation: 375 BTU/h
Management features
Quality of Service (QoS) support: Yes
MIB support: MIB II, Bridge MIB, Interface MIB, SMON MIB, IGMP MIB
System event log: Yes
Configuring Location Settings (CLI): Yes
Switch layer: L2/L3
Switch type: Managed
Weight & dimensions
Weight: 4.9 kg
Height: 44 mm
Width: 442 mm
Depth: 375 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.3af, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3bt
Virtual LAN features: Voice VLAN
Link aggregation: Yes
10G support: Yes
Number of VLANs: 4093
Cable types supported: Cat6, Cat7
Rate limiting: Yes
Port mirroring: Yes
Broadcast storm control: Yes
VLAN support: Yes
Flow control support: Yes
IP routing: Yes
Performance
Noise level: 48 dB
Packaging data
Package width: 480 mm
Package weight: 5.22 kg
Package depth: 570 mm
Package height: 100 mm
Packaging content
Manual: Yes
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 16
Power connector: AC-in jack
SFP28 ports quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
10G Ethernet (copper) ports quantity: 8
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Throughput: 292 Gbit/s
Packet buffer memory: 4 MB
Jumbo frames: 10240
Static route: Yes
MAC address table: 32000 entries
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 8
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
