Design
Number of fans: 2 fan(s)
Form factor: 1U
Rack mounting: Yes
Product colour: Black
LED indicators: Yes
Power
Power consumption (max): 920 W
Power supply included: Yes
Power source: AC
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Security
DHCP features: DHCP server
MAC address filtering: Yes
IGMP snooping: Yes
Access Control List (ACL): Yes
SSH/SSL support: Yes
Static port security: Yes
IGMP proxy: Yes
IGMP entries: 1024
Authentication type: IEEE 802.1x, RADIUS, TACACS+
Operational conditions
Heat dissipation: 683 BTU/h
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Quality of Service (QoS) support: Yes
Switch layer: L2/L3
Switch type: Managed
System event log: Yes
Configuring Location Settings (CLI): Yes
MIB support: MIB II, Bridge MIB, Interface MIB, SMON MIB, IGMP MIB
Weight & dimensions
Weight: 6.3 kg
Height: 44 mm
Depth: 440 mm
Width: 442 mm
Network
10G support: Yes
Number of VLANs: 4093
Flow control support: Yes
Port mirroring: Yes
Networking standards: IEEE 802.3at, IEEE 802.1w, IEEE 802.1D, IEEE 802.3af, IEEE 802.1s, IEEE 802.3bt
VLAN support: Yes
Rate limiting: Yes
Cable types supported: Cat6, Cat7
Virtual LAN features: Voice VLAN
Link aggregation: Yes
Broadcast storm control: Yes
IP routing: Yes
Performance
Noise level: 62 dB
Packaging data
Package height: 100 mm
Package depth: 570 mm
Package width: 480 mm
Package weight: 5.7 kg
Packaging content
Manual: Yes
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
10G Ethernet (copper) ports quantity: 8
SFP28 ports quantity: 2
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity: 48
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 40
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
Jumbo frames support: Yes
Packet buffer memory: 4 MB
MAC address table: 32000 entries
Throughput: 340 Gbit/s
Jumbo frames: 10240
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
