Design
Stackable: Yes
DIN rail mounting: Yes
Number of fans: 2 fan(s)
Housing material: Metal
Product colour: Black
Rack mounting: Yes
Form factor: 1U
Power
Power source: AC/PoE
Power supply included: Yes
AC input voltage: 100 - 240 V
Power consumption (max): 1650 W
AC input frequency: 50/60 Hz
Security
Authentication type: IEEE 802.1x, RADIUS, TACACS+
SSH/SSL support: Yes
Authentication: Guest VLAN
Access Control List (ACL): Yes
IGMP proxy: Yes
IGMP snooping: Yes
DHCP features: DHCP snooping, DHCP server, DHCP client, DHCP relay
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 715 BTU/h
Operating temperature (T-T): 0 - 40 °C
Management features
Switch type: Managed
ARP inspection: Yes
Quality of Service (QoS) support: Yes
Configuring Location Settings (CLI): Yes
Switch layer: L3
Web-based management: Yes
Weight & dimensions
Weight: 6.2 kg
Depth: 440 mm
Height: 44 mm
Width: 442 mm
Network
Spanning tree protocol: Yes
Flow control support: Yes
Broadcast storm control: Yes
Virtual LAN features: MAC address-based VLAN, Tagged VLAN, IP subnet–based VLAN, VLAN Identifier ( VLAN ID), MVRP, Port-based VLAN, Private VLAN, Protocol-based VLAN
Link aggregation: Yes
Port mirroring: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.1x, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.1AX, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1ab, IEEE 802.1Qav, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ac, IEEE 802.3an, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3u, IEEE 802.1ad, IEEE 802.3ba, IEEE 802.3at, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3bj
10G support: Yes
Number of VLANs: 4093
VLAN support: Yes
Cable length detection: Yes
Performance
Noise level: 60 dB
Firmware upgradeable: Yes
Packaging data
Rack rails: Yes
Mounting brackets included: Yes
Package weight: 6.45 kg
Package depth: 590 mm
Package height: 130 mm
Package width: 630 mm
Packaging content
Cables included: AC, Serial, Micro-USB
Quick start guide: Yes
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC)
Protocols
IP Source Guard (IPSG): Yes
GARP VLAN Registration Protocol (GVRP): Yes
Routing protocols: VRRP, OSPFv3, OSPFv2, BGP4, RIP-2
Ports & interfaces
Console port: RJ-45/micro-USB
USB Type-A ports quantity: 1
SFP28 ports quantity: 4
QSFP28 ports quantity: 2
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
Power connector: AC-in jack
10G Ethernet (copper) ports quantity: 12
Basic switching RJ-45 Ethernet ports quantity: 24
2.5G Ethernet (copper) ports quantity: 12
Number of management ports: 1 pc(s)
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
Store-and-forward: Yes
Static route: Yes
Throughput: 670 Mpps
Jumbo frames: 12288
Jumbo frames support: Yes
Packet buffer memory: 8 MB
Switching capacity: 900 Gbit/s
Number of static routes: 16000
MAC address table: 32000 entries
Power over Ethernet (PoE)
Power over Ethernet 4PPoE (PoE++) ports quantity: 24
Power over Ethernet (PoE) power per port: 90 W
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 720 W
Multicast features
Multicast Listener Discovery (MLD) snooping: Y
Multicast support: Yes
