Design
Product colour: Black
Stackable: Yes
Form factor: 1U
DIN rail mounting: Yes
Rack mounting: Yes
Housing material: Metal
Number of fans: 2 fan(s)
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (max): 1650 W
Power source: AC/PoE
Power supply included: Yes
Security
IGMP snooping: Yes
DHCP features: DHCP client, DHCP relay, DHCP snooping, DHCP server
IGMP proxy: Yes
SSH/SSL support: Yes
Authentication: Guest VLAN
Access Control List (ACL): Yes
Authentication type: IEEE 802.1x, RADIUS, TACACS+
Operational conditions
Heat dissipation: 715 BTU/h
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Management features
Web-based management: Yes
Switch layer: L3
Switch type: Managed
Configuring Location Settings (CLI): Yes
ARP inspection: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 7 kg
Depth: 440 mm
Height: 44 mm
Width: 442 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.1AX, IEEE 802.1w, IEEE 802.3ac, IEEE 802.3an, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1ad, IEEE 802.3ak, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3bj, IEEE 802.1ab, IEEE 802.1Qav, IEEE 802.3at, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1v, IEEE 802.1as
Port mirroring: Yes
Virtual LAN features: Voice VLAN, Tagged VLAN, Port-based VLAN, MAC address-based VLAN, IP subnet–based VLAN, VLAN Identifier ( VLAN ID), MVRP, Private VLAN, Protocol-based VLAN
Link aggregation: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Cable length detection: Yes
10G support: Yes
Number of VLANs: 4093
Flow control support: Yes
VLAN support: Yes
Performance
Firmware upgradeable: Yes
Noise level: 60 dB
Packaging data
Mounting brackets included: Yes
Package width: 630 mm
Rack rails: Yes
Package weight: 6.7 kg
Package depth: 590 mm
Package height: 130 mm
Packaging content
Cables included: Micro-USB, Serial, AC
Quick start guide: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), CE
Protocols
Routing protocols: OSPFv2, VRRP, OSPFv3, BGP4
IP Source Guard (IPSG): Yes
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
Console port: RJ-45/micro-USB
Basic switching RJ-45 Ethernet ports quantity: 48
Number of management ports: 1 pc(s)
USB Type-A ports quantity: 1
2.5G Ethernet (copper) ports quantity: 36
QSFP28 ports quantity: 2
10G Ethernet (copper) ports quantity: 12
SFP28 ports quantity: 4
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Throughput: 758 Mpps
Packet buffer memory: 8 MB
MAC address table: 32000 entries
Store-and-forward: Yes
Jumbo frames: 12288
Number of static routes: 16000
Switching capacity: 1020 Gbit/s
Static route: Yes
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 90 W
Power over Ethernet 4PPoE (PoE++) ports quantity: 48
Total Power over Ethernet (PoE) budget: 720 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
