Design Product colour: Black Cooling type: Active Built-in display: No Illumination: No Number of fans: 1 fan(s) Fan diameter: 14 cm
Power Max output current (+5Vsb): 2 A AC input frequency: 50/60 Hz Input current: 3 A Peak power: 600 W Max output current (+5V): 14 A Combined power (+5V): 90 W Max output current (+3.3V): 14 A Total power: 600 W Combined power (+5Vsb): 10 W Combined power (+12V): 600 W Efficiency: 85% AC input voltage: 180 - 240 V Combined power (-12V): 6 W Max output current (-12V): 0.5 A Power protection features: Over power, Short circuit, Over voltage Combined power (+3.3V): 90 W Max output current (+12V): 50 A Power Factor Correction (PFC) type: Active
Weight & dimensions Width: 121 mm Weight: 1.59 kg Depth: 215 mm Height: 290 mm
Performance Purpose: PC Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS ATX version: 2.31
Packaging data Package type: Box Package weight: 2.08 kg Certification: CE, TÜV
Certificates Compliance certificates: CE, TÜV mark
Ports & interfaces PCI Express power connectors (6+2 pin): 2 Floppy disk drive cable length: 93 cm Floppy drive power connector: 1 CPU power cable length: 60 cm CPU power connector (4+4 pin): Yes Motherboard power cable length: 55 cm Number of SATA power connectors: 6 PCI Express connector: Yes Floppy disk drive connector: Yes Cabling type: Non-Modular SATA power cable length: 620, 480, 760 mm PCI Express power cable length: 55 cm Number of PATA power connectors: 3 Motherboard power connector: 20+4 pin ATX EPS power connector (8-pin): Yes ATX power connector (20+4 pin): Yes
