Design Product colour: Black Number of fans: 1 fan(s) Fan diameter: 12 cm
Power Power protection features: Short circuit, Over power, Over voltage, Under voltage, Over current AC input frequency: 50 Hz Input current: 5 A AC input voltage: 230 V Max output current (+5Vsb): 2.5 A Combined power (+3.3V): 145 W Combined power (+5V): 145 W Max output current (+12V2): 23 A Efficiency: 88% Combined power (+12V): 450 W Total power: 550 W Power Factor Correction (PFC) type: Active Max output current (-12V): 0.5 A Max output current (+3.3V): 25 A Max output current (+12V1): 21 A Combined power (-12V): 18.5 W Combined power (+5Vsb): 18.5 W Max output current (+5V): 27 A
Weight & dimensions Weight: 1.75 kg Height: 86 mm Depth: 140 mm Width: 150 mm
Performance 80 PLUS certification: 80 PLUS Bronze Purpose: PC ATX version: 2.3 Power supply unit (PSU) form factor: ATX
Ports & interfaces Floppy disk drive connector: No Number of PATA power connectors: 4 CPU power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 1 Number of SATA power connectors: 4 PCI Express connector: Yes Cabling type: Non-Modular Motherboard power cable length: 45 cm CPU power cable length: 45 cm Motherboard power connector: 20+4 pin ATX
Logistics data Harmonized System (HS) code: 84733020
