Lenovo Legion T5 30IAX10 Intel Core Ultra 7 255HX 32 GB DDR5-SDRAM 2 TB SSD NVIDIA GeForce RTX 5070 Windows 11 Home Tower PC Black

Processor
Efficient cores: 12
Maximum turbo power: 160 W
Processor generation: Intel Core Ultra (Series 2)
Efficient-core base frequency: 1.8 GHz
Performance cores: 8
Performance-core base frequency: 2.4 GHz
Processor base power: 55 W
Efficient-core Max Turbo Frequency: 4.5 GHz
Performance-core Max Turbo Frequency: 5.2 GHz
Processor manufacturer: Intel
Processor boost frequency: 5.2 GHz
Processor cache: 30 MB
Processor family: Intel Core Ultra 7
Processor threads: 20
Processor model: 255HX
Processor cores: 20

Graphics
On-board GPU manufacturer: Intel
Discrete graphics memory type: GDDR7
On-board graphics card: Yes
On-board graphics card family: Intel Graphics
Discrete graphics card model: NVIDIA GeForce RTX 5070
Discrete graphics card: Yes
On-board graphics card model: Intel Graphics
Discrete graphics card memory: 12 GB

Memory
Memory layout (slots x size): 2 x 16 GB
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Maximum internal memory: 64 GB
Memory clock speed: 5600 MHz

Design
Volume: 30 L
Colour name: Eclipse Black
Product colour: Black
Chassis type: Tower

Power
Power supply input voltage: 100 - 240 V
Power supply: 850 W
Power supply input frequency: 50/60 Hz

Operational conditions
Non-operating altitude: 0 - 12192 m
Operating altitude: 0 - 3048 m
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -40 - 60 °C

Weight & dimensions
Height: 414 mm
Depth: 490.4 mm
Weight: 15 kg
Width: 211 mm

Network
Bluetooth version: 5.4
Mobile network connection: No
Bluetooth: Yes
Antenna type: 2x2
Wi-Fi: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)

Performance
Product type: PC
Trusted Platform Module (TPM): Yes
Audio chip: Realtek ALC623
Audio system: High Definition Audio

Display
Display included: No

Software
Operating system architecture: 64-bit
Operating system installed: Windows 11 Home

Storage
SSD interface: PCI Express 4.0
SSD form factor: M.2
NVMe: Yes
Total SSDs capacity: 2 TB
SSD capacity: 2 TB
Total storage capacity: 2 TB
Optical drive type: No
Storage media: SSD
Card reader integrated: No

Ports & interfaces
USB 3.2 Gen 2x2 Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 2.0 ports quantity: 4
Combo headphone/mic port: Yes
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3

Safety warning
Warnings: Dispose of used electronic devices at specialised disposal facilities., Ensure the unit is switched off and disconnected from the power source before carrying out any maintenance., Do not open the appliance housing without the appropriate tools and technical knowledge.

Neural processor unit (NPU)
Neural processor unit (NPU): Intel AI Boost
Windows Studio effects support: Yes
NPU performance up to: 13 TOPs
AI software frameworks supported by NPU: WebNN, ONNX RT, Windows ML, OpenVINO, DirectML
Sparsity support: Yes
Total processor performance up to: 33 TOPs
GPU performance up to: 8 TOPs
