Design
Product colour: Aluminium
Internal: Yes
LED indicators: Link, Activity
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 55 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 110 g
Depth: 69 mm
Width: 165 mm
Height: 17 mm
Network
Wake-on-LAN ready: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3, IEEE 802.1p, IEEE 802.3ad
Ethernet interface type: 10 Gigabit
Jumbo frames support: Yes
iSCSI support: Yes
Jumbo frames: 9.5
System requirements
Server operating systems supported: Windows Server 2008 R2, Windows Server 2008, Windows Server 2012 R2, Windows Server 2012, Windows Server 2003
Windows operating systems supported: Windows Vista Home Premium, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows Vista Enterprise x64, Windows Vista Business x64, Windows Vista Home Basic, Windows 8, Windows 7 Home Premium, Windows 7 Starter, Windows Vista Home Basic x64, Windows 7 Professional x64, Windows Vista Ultimate x64, Windows 7 Enterprise, Windows 7 Home Basic, Windows 7 Ultimate, Windows 7 Home Basic x64, Windows Vista Enterprise, Windows 7 Professional, Windows Vista Business, Windows 8.1, Windows Vista Ultimate, Windows 7 Ultimate x64, Windows Vista Home Premium x64
Packaging data
Drivers included: Yes
Package weight: 62 g
Package type: Box
Package depth: 220 mm
Package width: 145 mm
Package height: 30 mm
Quantity per pack: 1 pc(s)
Packaging content
Quick installation guide: Yes
Manual: Yes
Mounting brackets included: Yes
Ports & interfaces
Fiber ports quantity: 2
Connectivity technology: Wired
Interface: Fiber
Host interface: PCI Express
PCI version: 2.0
Fiber optic connector: SFP+
Other features
Power supply: 6.5 W
Intel® Virtualization Technology (Intel® VT): VT-c
Data transfer rate: 5 GT/s
PCI-SIG* SR-IOV Capable: Yes
Intel Virtual Machine Device Queues (VMDq): Yes
Logistics data
Harmonized System (HS) code: 85176990
