Technical details
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC)
Design
Product colour: Green
Country of origin: China
Internal: Yes
Component for: PC/Server
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -40 - 85 °C
Weight & dimensions
Height: 20 mm
Weight: 110 g
Depth: 68 mm
Width: 105 mm
Network
Ethernet interface type: Gigabit Ethernet, Fast Ethernet, 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet
Ethernet LAN: Yes
Supported network protocols: IPv4, IPv6
Networking standards: IEEE 802.3bz, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3u, IEEE 802.3az, IEEE 1588, IEEE 802.3an
Wake-on-LAN ready: Yes
Ethernet LAN data rates: 1000 Mbit/s, 100, 10, 10000 Mbit/s, 5000 Mbit/s, 2500
Jumbo frames support: Yes
Jumbo frames: 16000
Maximum data transfer rate: 10000 Mbit/s
Cabling technology: 10GBase-T
System requirements
Server operating systems supported: Windows Server 2012, Windows Server 2016
Linux operating systems supported: Yes
Windows operating systems supported: Windows 8.1, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1 Enterprise, Windows 7 Professional, Windows 7, Windows 10 Home, Windows 7 Starter x64, Windows 10 Enterprise x64, Windows 10 x64, Windows 10 Pro x64, Windows 8 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 8 Pro x64, Windows 8.1 Pro, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 IoT Enterprise, Windows 7 Professional x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 8 x64, Windows 10 Education, Windows 10 Home x64, Windows 8, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 7 Home Basic, Windows 7 Ultimate, Windows 10 Education x64
Packaging data
Package weight: 230 g
Package depth: 152 mm
Package height: 30 mm
Package width: 183 mm
Ports & interfaces
Interface: Ethernet
Host interface: PCI Express
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
Logistics data
Master (outer) cases per pallet: 19 pc(s)
Master (outer) case width: 490 mm
Master (outer) case gross weight: 15 kg
Master (outer) case length: 340 mm
Harmonized System (HS) code: 8517620090
Pallet gross length: 80 cm
Pallet gross height: 189.4 cm
Products per master (outer) case: 60 pc(s)
Pallet gross width: 120 cm
Master (outer) case height: 350 mm
Sustainability
Sustainability compliance: Yes
