Technical details
Pallet height (air): 164.4 cm
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Master (outer) cases per pallet (air): 28 pc(s)
Design
International Protection (IP) code: IP40
Product colour: Black
LED indicators: Power, System
DIN rail mounting: Yes
Power
Number of power supply units: 2
Surge protection voltage: 6 kV
DC input voltage: 12 - 58 V
Power source: DC
Power consumption (max): 10 W
Redundant power supply (RPS) support: Yes
Power supply included: No
Surge protection: Yes
Security
Security algorithms: HTTPS, SSH
DHCP features: DHCP server
IGMP snooping: Yes
Authentication type: IEEE 802.1x, RADIUS
IP-MAC-Port binding: Yes
Authentication: MAC-based authentication, Port-based authentication
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Storage relative humidity (H-H): 5 - 95%
Management features
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch layer: L2+
Configuring Location Settings (CLI): Yes
System event log: Yes
ARP inspection: Yes
Switch type: Managed
Weight & dimensions
Height: 158 mm
Depth: 115 mm
Width: 54 mm
Weight: 1.12 kg
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1s, IEEE 802.1D, IEEE 802.3z, IEEE 802.1x, IEEE 802.3u
VLAN support: Yes
Ethernet Ring Protection Switching (ERPS): Yes
Copper ethernet cabling technology: 1000BASE-X, 100BASE-TX, 10BASE-T, 1000BASE-T
Port mirroring: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Flow control support: Yes
10G support: No
Performance
Firmware upgradeable: Yes
Fanless: Yes
Packaging data
Package depth: 180 mm
Package height: 70 mm
Package weight: 1.38 kg
Package width: 230 mm
Terminal block included: Yes
DIN rail included: Yes
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45)
Certificates
Compliance certificates: Federal Communications Commission (FCC), UKCA, RoHS, CE
Protocols
IP Source Guard (IPSG): Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Console port: RJ-45
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
Other features
Remote administration: Y
Logistics data
Country of origin: China
Harmonized System (HS) code: 851762
Master (outer) case height: 250 mm
Master (outer) case length: 375 mm
Products per master (outer) case: 12 pc(s)
Master (outer) case width: 440 mm
Master (outer) case gross weight: 17.5 kg
Data transmission
Packet buffer memory: 12 MB
Switching capacity: 26 Gbit/s
MAC address table: 16000 entries
Jumbo frames support: Yes
Jumbo frames: 10000
Forwarding rate: 38.6 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
