Design
Product colour: Black
Reset button: Yes
LED indicators: Link, System, Power, Activity
Safety: UL
Rack mounting: Yes
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 80 W
Security
MAC address filtering: Yes
Security algorithms: SSL/TLS, SSH-2, SSH
Access Control List (ACL) ingress: 256
Neighbor discovery snooping: Yes
IGMP snooping: Yes
Root protection: Yes
BPDU filtering/protection: Yes
Password protection: Yes
DHCP features: DHCP client
Authentication type: HWTACACS+, RADIUS
Queue scheduling algorithms: Weighted Round Robin (WRR)
Static port security: Yes
DoS attack prevention: Yes
Loop protection: Yes
Access Control List (ACL): Yes
CPU defense: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50 °C
Heat dissipation: 267.95 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
ARP inspection: Yes
System event log: Yes
Switch layer: L2/L3/L4
MIB support: Y
Switch type: Managed
Weight & dimensions
Weight: 2 kg
Height: 44 mm
Depth: 180 mm
Width: 294 mm
Network
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.1D, IEEE 802.3z, IEEE 802.3af, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3at
VLAN support: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Fast leave: Yes
Rate limiting: Yes
10G support: No
Broadcast storm control: Yes
Virtual LAN features: Tagged VLAN, Port-based VLAN
Flow control support: Yes
Port mirroring: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Performance
Firmware upgradeable: Yes
Noise level: 0 dB
Internal memory: 16 MB
Plug and Play: Yes
Mean time between failures (MTBF): 118824 h
Packaging data
Package height: 85 mm
Package type: Box
Package weight: 2.18 kg
Package depth: 270 mm
Package width: 375 mm
Resource CD: Yes
Packaging content
Cables included: AC
Quick start guide: Yes
Rack mount kit: Yes
Protocols
IPv4 & IPv6 features: IPv6 ping, Dual stack IPv4/IPv6, IPv6 Telnet, IPv6 tracert
Management protocols: SNMP v1/v2c/v3, Telnet
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
SFP module slots quantity: 2
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
Data transmission
Forwarding rate: 14.9 Mpps
Store-and-forward: Yes
Switching capacity: 20 Gbit/s
MAC address table: 8000 entries
Jumbo frames support: Yes
Packet buffer memory: 4.1 MB
Jumbo frames: 10000
Number of queues: 8
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 70 W
Power over Ethernet plus (PoE+) ports quantity: 8
Multicast features
Multicast Listener Discovery (MLD) snooping: Y
Optical fiber
Fiber ethernet cabling technology: 1000BASE-X
