LevelOne 15dBi 5GHz Directional Dual-Polarization Panel Antenna, Indoor /Outdoor

Features
Antenna type: Directional antenna
Antenna connector type: N-type
Product colour: Grey
Maximum cable loss with connectors: -10 dB
Survival wind speed: 180 km/h
Protection features: Water resistant, Snow resistant, Dust resistant
Voltage Standing Wave Ratio (VSWR): 2.0
Polarization: Dual polarization
Purpose: Indoor & outdoor

Operational conditions
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%

Weight & dimensions
Weight: 208 g
Width: 137.5 mm
Depth: 162.5 mm
Height: 16 mm

Performance
Networking standards: IEEE 802.11n, IEEE 802.11a
Frequency band: 5.1 ~ 5.9 GHz
Antenna gain level (max): 15 dBi
Horizontal beam width: 22°
Vertical beam width: 15°
Impedance: 50 Ω

Packaging data
Package type: Box
Package height: 74 mm
Package depth: 218 mm
Package weight: 726 g
Package width: 161 mm

Packaging content
Mounting kit: Yes
Quick installation guide: Yes

Logistics data
Country of origin: Taiwan
Master (outer) case width: 370 mm
Master (outer) case height: 340 mm
Harmonized System (HS) code: 85177100
Master (outer) case length: 450 mm
Master (outer) case gross weight: 15.5 kg
Products per master (outer) case: 20 pc(s)
