Design
Housing material: Metal
LED indicators: Activity, PoE, Power
Product colour: Grey
Power
Power protection features: Over current
Input current: 5 A
Power consumption (typical): 120 W
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Operational conditions
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 75 °C
Weight & dimensions
Weight: 2.85 kg
Width: 200 mm
Height: 44 mm
Depth: 480 mm
Network
Cable types supported: Cat5, Cat4, Cat3
Auto-negotiation: Yes
10G support: No
Flow control support: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX
Auto MDI/MDI-X: Yes
Full duplex: Yes
Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Performance
Buffer size: 160 KB
Plug and Play: Yes
Packaging data
Rubber feet: Yes
Package height: 90 mm
Package type: Box
Package weight: 3.7 kg
Package width: 260 mm
Package depth: 535 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Logistics data
Master (outer) case width: 520 mm
Master (outer) case length: 560 mm
Master (outer) case height: 280 mm
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 19.8 kg
Products per master (outer) case: 5 pc(s)
Country of origin: Taiwan
Data transmission
MAC address table: 4000 entries
Packet forwarding rate (10 Mbps): 14880 pps
Packet forwarding rate (100 Mbps): 148000 pps
Store-and-forward: Yes
Switching capacity: 3.2 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 16
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
