Design
Product colour: Grey
Stackable: No
Rack mounting: Yes
LED indicators: Activity, PoE, Power, LAN
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Input current: 5 A
Power consumption (typical): 500 W
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 200 mm
Weight: 2.85 kg
Depth: 480 mm
Height: 44 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Cable types supported: Cat5
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX
Auto-negotiation: Yes
10G support: No
Full duplex: Yes
Performance
Buffer size: 160 KB
Packaging data
Package depth: 535 mm
Package height: 90 mm
Package width: 260 mm
Package weight: 3.7 kg
Packaging content
Quick start guide: Yes
Cables included: AC
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity: 16
Logistics data
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
Data transmission
Packet forwarding rate (100 Mbps): 148000 pps
Store-and-forward: Yes
Packet forwarding rate (10 Mbps): 14880 pps
MAC address table: 4096 entries
Switching capacity: 3.2 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 16
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 480 W
