Design
Stackable: No
Rack mounting: Yes
Product colour: Grey
LED indicators: Link, Power, Activity, LAN
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 6.2 W
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 44 mm
Depth: 208 mm
Weight: 2.6 kg
Height: 440 mm
Network
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T
Networking standards: IEEE 802.3, IEEE 802.1p, IEEE 802.3az, IEEE 802.3x, IEEE 802.3u
Cable types supported: Cat5
Full duplex: Yes
10G support: No
Performance
Buffer size: 160 KB
Packaging data
Package height: 550 mm
Package weight: 2.7 kg
Package width: 308 mm
Package depth: 94 mm
Wall mounting kit: Yes
Packaging content
Quick start guide: Yes
Cables included: AC
Protocols
Switching protocols: CSMA/CD
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Data transmission
MAC address table: 8192 entries
Switching capacity: 3.2 Gbit/s
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
