Features Product colour: Silver Form factor: SFP Plug and Play: Yes Hot-swap: Yes
Power Power consumption (typical): 1 W
Operational conditions Operating temperature (T-T): 0 - 70 °C Storage relative humidity (H-H): 5 - 85% Storage temperature (T-T): -40 - 85 °C Operating relative humidity (H-H): 5 - 85%
Weight & dimensions Height: 13 mm Width: 55.9 mm Weight: 15.5 g Depth: 13.4 mm
Performance Tx power (max): -3 dBmW Maximum data transfer rate: 2500 Mbit/s Wavelength: 850 nm Copper ethernet cabling technology: 2.5GBASE Digital Diagnostics Monitoring (DDM): Yes SFP transceiver type: Fiber optic Maximum transfer distance: 300 m Fiber cable diameters supported (core/cladding): 50/125 Multi-mode fiber (MMF) supported: Yes Fiber optic connector: LC Interface type: SFP Tx power (min): -9 dBmW
Packaging data Package width: 110 mm Package weight: 41.66 g Package depth: 67 mm Package height: 25 mm
Packaging content Quantity per pack: 1 pc(s)
Certificates Compliance certificates: CB, TÜV mark, RoHS, CE, Federal Communications Commission (FCC), UL
Logistics data Customs product code (TARIC): 8517620000 Master (outer) case height: 250 mm Country of origin: Taiwan Master (outer) cases per pallet: 34 pc(s) Pallet gross width: 120 cm Master (outer) case gross weight: 5.5 kg Pallet gross height: 164.4 cm Pallet gross length: 80 cm Products per master (outer) case: 100 pc(s) Master (outer) case length: 343 mm Master (outer) case width: 365 mm
