Features Form factor: SFP Hot-swap: Yes Product colour: Silver Plug and Play: Yes
Power Power consumption (typical): 1 W
Operational conditions Storage temperature (T-T): -40 - 85 °C Operating relative humidity (H-H): 5 - 85% Operating temperature (T-T): 0 - 70 °C Storage relative humidity (H-H): 5 - 85%
Weight & dimensions Depth: 13.4 mm Width: 55.9 mm Height: 13 mm Weight: 15.5 g
Performance Copper ethernet cabling technology: 2.5GBASE Maximum data transfer rate: 2500 Mbit/s Interface type: SFP Wavelength: 1310 nm Maximum transfer distance: 20000 m Digital Diagnostics Monitoring (DDM): Yes Fiber optic connector: LC Tx power (max): 0 dBmW Fiber cable diameters supported (core/cladding): 9/125 µm Tx power (min): -5 dBmW Single-mode fiber (SMF) supported: Yes SFP transceiver type: Fiber optic
Packaging data Package weight: 41.66 g Package width: 110 mm Package depth: 67 mm Package height: 25 mm
Packaging content Quantity per pack: 1 pc(s)
Certificates Compliance certificates: UL, CB, Federal Communications Commission (FCC), TÜV mark, RoHS, CE
Logistics data Products per master (outer) case: 100 pc(s) Country of origin: Taiwan Master (outer) cases per pallet: 34 pc(s) Pallet gross length: 80 cm Pallet gross width: 120 cm Master (outer) case height: 250 mm Master (outer) case length: 343 mm Pallet gross height: 164.4 cm Master (outer) case gross weight: 5.5 kg Master (outer) case width: 365 mm Customs product code (TARIC): 8517620000
