Features Hot-swap: Yes Plug and Play: Yes Form factor: SFP Product colour: Silver
Power Power consumption (typical): 1 W
Operational conditions Storage temperature (T-T): -40 - 85 °C Operating temperature (T-T): 0 - 70 °C Operating relative humidity (H-H): 5 - 85% Storage relative humidity (H-H): 5 - 85%
Weight & dimensions Height: 13 mm Depth: 13.4 mm Width: 55.9 mm Weight: 15.5 g
Performance Digital Diagnostics Monitoring (DDM): Yes Interface type: SFP Wavelength: 1550 nm Copper ethernet cabling technology: 2.5GBASE Tx power (max): 3 dBmW Maximum transfer distance: 40000 m Tx power (min): -2 dBmW Single-mode fiber (SMF) supported: Yes Fiber optic connector: LC SFP transceiver type: Fiber optic Fiber cable diameters supported (core/cladding): 9/125 µm Maximum data transfer rate: 2500 Mbit/s
Packaging data Package height: 25 mm Package depth: 67 mm Package weight: 41.66 g Package width: 110 mm
Packaging content Quantity per pack: 1 pc(s)
Certificates Compliance certificates: UL, CB, Federal Communications Commission (FCC), RoHS, CE, TÜV mark
Logistics data Pallet gross width: 120 cm Master (outer) case height: 250 mm Master (outer) case width: 365 mm Master (outer) case gross weight: 5.5 kg Master (outer) case length: 343 mm Master (outer) cases per pallet: 34 pc(s) Pallet gross height: 164.4 cm Pallet gross length: 80 cm Products per master (outer) case: 100 pc(s) Customs product code (TARIC): 8517620000 Country of origin: Taiwan
