Technical details
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Master (outer) cases per pallet (air): 26 pc(s)
Pallet height (air): 167.4 cm
Design
International Protection (IP) code: IP40
LED indicators: System, USB, Power
Product colour: Black
DIN rail mounting: Yes
Power
Surge protection: Yes
Redundant power supply (RPS) support: Yes
Power consumption (max): 22 W
Power source: DC
Power supply included: No
Surge protection voltage: 6 kV
Number of power supply units: 2
Security
Authentication: MAC-based authentication, Port-based authentication
Packet filtering: Y
IP-MAC-Port binding: Yes
DHCP features: DHCP server
Authentication type: IEEE 802.1x, RADIUS
IGMP snooping: Yes
Access Control List (ACL): Yes
Operational conditions
Operating temperature (T-T): -40 - 80 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 85 °C
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2+
System event log: Yes
ARP inspection: Yes
Switch type: Managed
Weight & dimensions
Width: 110 mm
Depth: 115 mm
Height: 158 mm
Weight: 2.08 kg
Network
Networking standards: IEEE 802.1ab, IEEE 802.3, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1x, IEEE 802.3u
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-X, 10BASE-T, 1000BASE-T
VLAN support: Yes
10G support: No
Flow control support: Yes
Spanning tree protocol: Yes
Ethernet Ring Protection Switching (ERPS): Yes
Link aggregation: Yes
Performance
Fanless: Yes
Packaging data
Package width: 230 mm
Package weight: 2.41 kg
Package height: 142 mm
Package depth: 180 mm
Terminal block included: Yes
DIN rail included: Yes
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45)
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, UKCA
Protocols
IP Source Guard (IPSG): Yes
Ports & interfaces
USB 2.0 ports quantity: 1
Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 4
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 16
Logistics data
Country of origin: China
Products per master (outer) case: 6 pc(s)
Harmonized System (HS) code: 851762
Master (outer) case gross weight: 15.2 kg
Master (outer) case width: 580 mm
Master (outer) case length: 310 mm
Master (outer) case height: 255 mm
Data transmission
Jumbo frames support: Yes
Switching capacity: 52 Gbit/s
Jumbo frames: 10000
Forwarding rate: 77.3 Mpps
Packet buffer memory: 12 MB
MAC address table: 16000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
