Technical details
Pallet gross length: 80 cm
Pallet gross width: 120 cm
Design
International Protection (IP) code: IP40
Product colour: Black
LED indicators: System, Ring, USB
DIN rail mounting: Yes
Power
Input voltage: 12 - 75 V
Redundant power supply (RPS) support: Yes
Surge protection: Yes
Power consumption (max): 27 W
Power source: DC
Surge protection voltage: 6 kV
Security
MAC address filtering: Yes
Security algorithms: HTTPS
Packet filtering: Y
IGMP snooping: Yes
Authentication type: IEEE 802.1x
IP-MAC-Port binding: Yes
Password protection: Yes
DHCP features: DHCP server
Queue scheduling algorithms: SP, Weighted Round Robin (WRR)
Loop protection: Yes
Access Control List (ACL): Yes
Operational conditions
Operating temperature (T-T): -40 - 80 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 85 °C
Management features
Web-based management: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
Quality of Service (QoS) support: Yes
System event log: Yes
Switch layer: L2+
Switch type: Managed
Weight & dimensions
Weight: 1.79 kg
Height: 158 mm
Depth: 115 mm
Width: 110 mm
Network
Networking standards: IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.1x, IEEE 802.1D, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x
Virtual LAN features: IP subnet–based VLAN, MAC address-based VLAN, Stacked VLAN, VLAN mapping, Protocol-based VLAN
Port mirroring: Yes
Ethernet Ring Protection Switching (ERPS): Yes
VLAN support: Yes
Rate limiting: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Cable length detection: Yes
Spanning tree protocol: Yes
10G support: Yes
Flow control support: Yes
Performance
Firmware upgradeable: Yes
Telnet: Yes
Dying Gasp: Yes
Fanless: Yes
Mean time between failures (MTBF): 200000 h
Packaging data
Package height: 138 mm
Package width: 232 mm
Package weight: 2.12 kg
Package depth: 180 mm
DIN rail included: Yes
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45) to DB9
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, UKCA
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
IP Source Guard (IPSG): Yes
Ports & interfaces
SFP module slots quantity: 8
Basic switching RJ-45 Ethernet ports quantity: 8
Console port: RJ-45
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
USB Type-A ports quantity: 1
Gigabit Ethernet (copper) ports quantity: 8
SFP+ module slots quantity: 4
Other features
Terminal block port: Yes
Logistics data
Country of origin: China
Products per master (outer) case: 6 pc(s)
Pallet gross height: 167.4 cm
Master (outer) case length: 375 mm
Harmonized System (HS) code: 851762
Master (outer) case width: 440 mm
Master (outer) case height: 255 mm
Master (outer) case gross weight: 15 kg
Data transmission
MAC address table: 16000 entries
Static route: Yes
Jumbo frames support: Yes
Packet buffer memory: 12 MB
Switching capacity: 112 Gbit/s
Jumbo frames: 10000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
