Technical details
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Design
Stackable: No
DIN rail mounting: Yes
International Protection (IP) code: IP40
Product colour: Black
LED indicators: Power, Ring, USB, System
Power
Surge protection voltage: 6 kV
Input voltage: 12 - 75 V
Power consumption (max): 25 W
Surge protection: Yes
Power source: DC
Redundant power supply (RPS) support: Yes
Security
DHCP features: DHCP server
IGMP snooping: Yes
IP-MAC-Port binding: Yes
Authentication type: IEEE 802.1x
Queue scheduling algorithms: SP, Weighted Round Robin (WRR)
Access Control List (ACL): Yes
Loop protection: Yes
MAC address filtering: Yes
Security algorithms: HTTPS
Password protection: Yes
Operational conditions
Operating temperature (T-T): -40 - 80 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 85 °C
Management features
Switch layer: L2+
System event log: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
Switch type: Managed
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 110 mm
Height: 158 mm
Depth: 115 mm
Weight: 1.79 kg
Network
Port mirroring: Yes
Cable length detection: Yes
10G support: Yes
Flow control support: Yes
Rate limiting: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Virtual LAN features: MAC address-based VLAN, IP subnet–based VLAN, Stacked VLAN, VLAN mapping, Protocol-based VLAN
Ethernet Ring Protection Switching (ERPS): Yes
Networking standards: IEEE 802.1ad, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab
VLAN support: Yes
Performance
Telnet: Yes
Dying Gasp: Yes
Firmware upgradeable: Yes
Fanless: Yes
Mean time between failures (MTBF): 200000 h
Packaging data
Terminal block included: Yes
Package height: 138 mm
Package weight: 2.12 kg
Package depth: 180 mm
DIN rail included: Yes
Package width: 232 mm
Packaging content
Cables included: LAN (RJ-45) to DB9
Quick start guide: Yes
Certificates
Compliance certificates: UKCA, RoHS, CE, Federal Communications Commission (FCC)
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
IP Source Guard (IPSG): Yes
Ports & interfaces
Console port: RJ-45
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
USB Type-A ports quantity: 1
SFP module slots quantity: 8
Other features
Terminal block port: Yes
Logistics data
Master (outer) case length: 375 mm
Master (outer) case width: 440 mm
Master (outer) case height: 255 mm
Pallet gross height: 167.4 cm
Harmonized System (HS) code: 851762
Country of origin: China
Products per master (outer) case: 6 pc(s)
Master (outer) case gross weight: 15 kg
Data transmission
Packet buffer memory: 12 MB
MAC address table: 16000 entries
Jumbo frames: 10000
Static route: Yes
Switching capacity: 52 Gbit/s
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
