Design Rack mounting: Yes Product colour: Black LED indicators: Activity, Link, Power
Power AC input frequency: 50 - 60 Hz AC input voltage: 100 - 240 V Power consumption (typical): 10 W
Operational conditions Storage temperature (T-T): -40 - 70 °C Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 10 - 90% Storage relative humidity (H-H): 5 - 95%
Management features Quality of Service (QoS) support: Yes Switch type: Unmanaged
Weight & dimensions Weight: 1.45 kg Width: 140 mm Height: 44 mm Depth: 440 mm
Network Copper ethernet cabling technology: 10BASE-T, 100BASE-TX Networking standards: IEEE 802.3u, IEEE 802.3z, IEEE 802.3, IEEE 802.1p Auto MDI/MDI-X: Yes Auto-negotiation: Yes Cable types supported: Cat5 Rate limiting: Yes Flow control support: Yes Full duplex: Yes MAC address auto-learning supported: Yes 10G support: No
Performance Maximum cable length: 100 m
Packaging data Package height: 77 mm Package width: 224 mm Package weight: 2.13 kg Package depth: 486 mm
Packaging content Rack mount kit: Yes Cables included: AC Quick start guide: Yes
Protocols Switching protocols: CSMA, CD
Ports & interfaces Basic switching RJ-45 Ethernet ports quantity: 24 Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100) Power connector: DC-in jack
Logistics data Master (outer) case length: 500 mm Harmonized System (HS) code: 85176990 Country of origin: China Master (outer) case height: 240 mm Master (outer) case gross weight: 11.6 kg Master (outer) case width: 405 mm
Data transmission Store-and-forward: Yes Switching capacity: 4.8 Gbit/s Packet buffer memory: 0.16 MB MAC address table: 8192 entries
Power over Ethernet (PoE) Power over Ethernet (PoE): No
