Design Product colour: Silver, Blue Number of fans: 0 fan(s)
Power Power protection features: Short circuit, Over voltage, Overload Total power: 120 W AC input voltage: 90 -264 V AC input frequency: 47 - 63 Hz Input current: 2.25 A Hold time: 16 ms
Operational conditions Operating relative humidity (H-H): 0 - 90% Operating temperature (T-T): -20 - 70 °C
Weight & dimensions Width: 40 mm Height: 125.2 mm Weight: 530 g Depth: 113.5 mm
Performance Mean time between failures (MTBF): 2636800 h
Packaging data Package weight: 700 g Package width: 60 mm Package type: Box Package depth: 140 mm Package height: 143 mm
Other features Maximum current: 5 A Output voltage note: 24V Voltage tolerance: 1%
Logistics data Master (outer) case width: 310 mm Master (outer) cases per pallet: 20 pc(s) Harmonized System (HS) code: 8504403090 Master (outer) case gross weight: 14 kg Country of origin: China Master (outer) case length: 310 mm Master (outer) case height: 305 mm
