Design Number of fans: 0 fan(s) Product colour: Blue, Silver
Power Total power: 480 W Power protection features: Short circuit, Over voltage, Overload Hold time: 16 ms AC input frequency: 47 - 63 Hz AC input voltage: 90 - 264 V Input current: 4.8 A
Operational conditions Storage relative humidity (H-H): 10 - 95% Operating temperature (T-T): -20 - 70 °C Operating relative humidity (H-H): 10 - 95% Storage temperature (T-T): -40 - 85 °C
Weight & dimensions Height: 125.2 mm Depth: 128.5 mm Weight: 1.42 kg Width: 85.5 mm
Performance Mean time between failures (MTBF): 1041600 h
Packaging data Package weight: 1.5 kg Package type: Box Package height: 150 mm Package width: 122 mm Package depth: 171 mm
Other features Output voltage note: 24 Voltage tolerance: 1%
Logistics data Master (outer) cases per pallet: 20 pc(s) Master (outer) case width: 266 mm Country of origin: China Harmonized System (HS) code: 8504403090 Master (outer) case gross weight: 11.4 kg Master (outer) case height: 323 mm Master (outer) case length: 361 mm
