Design Product colour: Blue, Silver Number of fans: 0 fan(s)
Power Power protection features: Short circuit, Over voltage, Overload Total power: 75 W Hold time: 16 ms AC input frequency: 47 - 63 Hz AC input voltage: 90 - 264 V Input current: 1.45 A
Operational conditions Operating temperature (T-T): -20 - 70 °C Operating relative humidity (H-H): 0 - 90%
Weight & dimensions Height: 125.2 mm Width: 32 mm Depth: 102 mm Weight: 430 g
Performance Mean time between failures (MTBF): 486200 h
Packaging data Package width: 53 mm Package type: Box Package height: 147 mm Package weight: 700 g Package depth: 132 mm
Other features Output voltage note: 24V Voltage tolerance: 1%
Logistics data Master (outer) cases per pallet: 20 pc(s) Master (outer) case height: 393 mm Master (outer) case length: 313 mm Master (outer) case width: 282 mm Harmonized System (HS) code: 8504403090 Master (outer) case gross weight: 19.6 kg Country of origin: China
