Design
On/off switch: Yes
Product colour: Black
Rack mounting: Yes
LED indicators: Uplink, Power, LAN, PoE
Housing material: Metal
Power
AC input frequency: 50 - 60 Hz
Power protection features: Overheating, Over current, Over voltage
AC input voltage: 100 - 240 V
Operational conditions
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 200 mm
Height: 440 mm
Depth: 44 mm
Weight: 2.9 kg
Network
Networking standards: IEEE 802.3at, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x
Full duplex: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported: Cat3, Cat4, Cat7, Cat5, Cat5e, Cat6
10G support: No
Flow control support: Yes
Performance
Mean time between failures (MTBF): 50000 h
Packaging data
Package depth: 95 mm
Package weight: 3.5 kg
Package width: 260 mm
Package height: 540 mm
Packaging content
Cables included: AC
Manual: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 26
Gigabit Ethernet (copper) ports quantity: 2
Fast Ethernet (copper) ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: AC-in jack
Logistics data
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 18 kg
Master (outer) case height: 555 mm
Master (outer) case width: 510 mm
Master (outer) case length: 280 mm
Data transmission
Switching capacity: 8.8 Gbit/s
Jumbo frames support: Yes
MAC address table: 4000 entries
Packet forwarding rate (10 Mbps): 14880 pps
Jumbo frames: 10000
Packet forwarding rate (100 Mbps): 148800 pps
Packet forwarding rate (1 Gbps): 1488000 pps
Packet buffer memory: 0.512 MB
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 150 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet plus (PoE+) ports quantity: 24
