Technical details
Pallet gross length: 100 cm
Pallet gross width: 120 cm
Pallet height (air): 164.9 cm
Master (outer) cases per pallet (air): 18 pc(s)
Design
Rack mounting: Yes
Product colour: Black
Power
Power supply included: Yes
Number of power supply units: 2
Redundant power supply (RPS) support: Yes
Power source: AC
AC input frequency: 50 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 26 W
Power consumption (max): 64 W
Security
IGMP snooping: Yes
DoS attack prevention: Yes
IP-MAC-Port binding: Yes
Queue scheduling algorithms: SP, WRR+SP, Weighted random early detection (WRED), Weighted Round Robin (WRR)
Authentication type: IEEE 802.1x, RADIUS, TACACS+
Root protection: Yes
BPDU filtering/protection: Yes
DHCP features: DHCP snooping, DHCP Option 82
Access Control List (ACL): Yes
MAC address filtering: Yes
Operational conditions
Heat dissipation: 238.91 BTU/h
Operating temperature (T-T): -10 - 50 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 70 °C
Management features
Traffic classification: Yes
Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes
Weight & dimensions
Weight: 4.25 kg
Height: 44.5 mm
Depth: 300 mm
Width: 442.5 mm
Network
Fast leave: Yes
Number of VLANs: 4000
10G support: No
6to4 tunnel: Yes
Policy-based routing: Yes
Virtual LAN features: Private VLAN, Protocol-based VLAN
MAC address auto-aging supported: Yes
MAC address auto-learning supported: Yes
Ethernet Ring Protection Switching (ERPS): Yes
Link aggregation: Yes
Spanning tree protocol: Yes
VLAN mapping type: N:1 VLAN mapping, 1:1 VLAN mapping
Networking standards: IEEE 802.1w, IEEE 802.3az, IEEE 802.1AE, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1D
VLAN support: Yes
Performance
Manually configured tunnel: Yes
Fanless: No
sFlow: Yes
Noise level: 57 dB
Flash memory: 4096 MB
Internal memory: 2048 MB
Mean time between failures (MTBF): 200000 h
Packaging data
Rubber feet: Yes
Package width: 576 mm
Package weight: 7.45 kg
Package depth: 448 mm
Package height: 94 mm
Packaging content
Rack mount kit: Yes
Quick start guide: Yes
Cables included: AC
Certificates
Compliance certificates: RoHS, UKCA, Federal Communications Commission (FCC)
Protocols
Routing protocols: RIP-1, OSPF, HSRP, BGP, BGP4+, RIPng, VRRP, OSPFv3, RIP-2, MPLS
Intra-Site Automatic Tunnel Addressing Protocol (ISATAP): Yes
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: No
Number of management ports: 1 pc(s)
Console port: RJ-45
SFP+ module slots quantity: 24
USB 2.0 ports quantity: 1
QSFP28 ports quantity: 2
Logistics data
Master (outer) case length: 462 mm
Master (outer) case width: 605 mm
Master (outer) case gross weight: 15.7 kg
Master (outer) case height: 215 mm
Products per master (outer) case: 2 pc(s)
Country of origin: China
Harmonized System (HS) code: 851762
Data transmission
MAC address table: 128000 entries
Packet buffer memory: 4.5 MB
Jumbo frames support: Yes
Path MTU discovery: Yes
Jumbo frames: 16000
Forwarding rate: 660 Mpps
Switching capacity: 880 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Multicast features: Multicast traffic suppression
