Design
Product colour: Black
Stackable: Yes
Rack mounting: Yes
LED indicators: Yes
Power
AC input frequency: 47/63 Hz
AC input voltage: 100 - 240 V
Power consumption (max): 63.96 W
Power consumption (typical): 49.6 W
Security
SSH/SSL support: Yes
BPDU filtering/protection: Yes
Auto-edge port: Yes
Authentication: MAC-based authentication
Loop protection: Yes
Access Control List (ACL): Yes
IGMP snooping: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 50 °C
Management features
Web-based management: Yes
System event log: Yes
Traffic classification: Yes
ARP inspection: Yes
Switch layer: L3
Switch type: Managed
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 440 mm
Depth: 415 mm
Height: 44 mm
Weight: 5.7 kg
Network
Networking standards: IEEE 802.3u, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1v, IEEE 802.1x, IEEE 802.1D, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ab, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w
Port mirroring: Yes
Virtual LAN features: Port-based VLAN, Private VLAN
MAC address auto-aging supported: Yes
Flow control support: Yes
Spanning tree protocol: Yes
Rate limiting: Yes
MAC address auto-learning supported: Yes
Active link detection: Yes
Full duplex: Yes
10G support: Yes
VLAN support: Yes
Performance
Firmware upgradeable: Yes
Buffer size: 2048 KB
Packaging data
Package width: 530 mm
Package type: Box
Package height: 135 mm
Package depth: 420 mm
Protocols
Management protocols: Telnet, SNMP, SNTP, RMON,
Supported network protocols: IPv6, IPv4, BOOTP
Ports & interfaces
Console port: RJ-45
Combo SFP ports quantity: 4
SFP/SFP+ slots quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
SFP module slots quantity: 4
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Packet forwarding rate (10 Mbps): 14880 pps
Packet forwarding rate (100 Mbps): 148000 pps
Forwarding rate: 95.2 Mpps
Jumbo frames: 9000
Store-and-forward: Yes
Number of static routes: 512
Packet forwarding rate (1 Gbps): 1488000 pps
Number of queues: 8
Jumbo frames support: Yes
Switching capacity: 128 Gbit/s
MAC address table: 16000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Multicast MAC address table: 1024 entries
