Technical details
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Master (outer) cases per pallet (air): 14 pc(s)
Pallet height (air): 177.6 cm
Design
Rack mounting: Yes
International Protection (IP) code: IP40
Product colour: Black
LED indicators: USB, System, Power
Power
Power supply included: Yes
Surge protection: Yes
Redundant power supply (RPS) support: Yes
Power consumption (max): 36 W
AC input frequency: 50/60 Hz
Power source: AC
AC input voltage: 100 - 240 V
DC input voltage: 36 - 75 V
Surge protection voltage: 6 kV
Security
Authentication: MAC-based authentication, Port-based authentication
Security algorithms: SSH, HTTPS
Access Control List (ACL): Yes
MAC address filtering: Yes
MAC address entries: Static MAC address entries, Dynamic MAC address entries
Queue scheduling algorithms: Weighted Round Robin (WRR)
Packet filtering: Y
Operational conditions
Operating temperature (T-T): -40 - 80 °C
Storage temperature (T-T): -40 - 85 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Management features
System event log: Yes
Switch layer: L2+
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Height: 280 mm
Depth: 45 mm
Width: 440 mm
Weight: 4.14 kg
Network
Port mirroring: Yes
10G support: No
Broadcast storm control: Yes
Rate limiting: Yes
Flow control support: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 100BASE-X, 1000BASE-T
VLAN support: Yes
Networking standards: IEEE 802.1ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1s, IEEE 802.3u, IEEE 802.1D, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.1x
Port trunking: Yes
Virtual LAN features: MAC address-based VLAN, Stacked VLAN, VLAN mapping, Protocol-based VLAN
Ethernet Ring Protection Switching (ERPS): Yes
Spanning tree protocol: Yes
Performance
Mean time between failures (MTBF): 200000 h
Fanless: Yes
Packaging data
Package depth: 390 mm
Package height: 95 mm
Package weight: 5.29 kg
Package width: 525 mm
Terminal block included: Yes
Packaging content
Quick start guide: Yes
Rack mount kit: Yes
Cables included: AC, LAN (RJ-45)
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, UKCA
Protocols
IP Source Guard (IPSG): Yes
IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL)
Ports & interfaces
Console port: RJ-45
Combo SFP ports quantity: 8
Basic switching RJ-45 Ethernet ports type: No
SFP module slots quantity: 20
USB 2.0 ports quantity: 1
Logistics data
Master (outer) case length: 400 mm
Harmonized System (HS) code: 851762
Master (outer) case gross weight: 22.5 kg
Master (outer) case width: 535 mm
Products per master (outer) case: 4 pc(s)
Master (outer) case height: 408 mm
Country of origin: China
Data transmission
Jumbo frames support: Yes
Packet buffer memory: 12 MB
MAC address table: 16000 entries
Switching capacity: 68 Gbit/s
Forwarding rate: 101.1 Mpps
Jumbo frames: 10000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
