Design
Product colour: Black
LED indicators: Uplink, Power, LAN, PoE
Rack mounting: Yes
On/off switch: Yes
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Operational conditions
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Weight: 2.8 kg
Depth: 480 mm
Width: 195 mm
Height: 45 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3u
Full duplex: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Cable types supported: Cat3, Cat7, Cat6, Cat4, Cat5, Cat5e
Flow control support: Yes
10G support: No
Performance
Mean time between failures (MTBF): 74000 h
Packaging data
Package depth: 534 mm
Package width: 255 mm
Package weight: 3.3 kg
Package type: Box
Package height: 95 mm
Rubber feet: Yes
Packaging content
Quick start guide: Yes
Cables included: AC
Rack mount kit: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity: 32
Fast Ethernet (copper) ports quantity: 32
Gigabit Ethernet (copper) ports quantity: 2
Logistics data
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
Master (outer) case length: 555 mm
Master (outer) case width: 510 mm
Master (outer) case gross weight: 17.8 kg
Master (outer) case height: 280 mm
Products per master (outer) case: 5 pc(s)
Data transmission
Switching capacity: 10.4 Gbit/s
Packet buffer memory: 8 MB
MAC address table: 32000 entries
Packet forwarding rate (1 Gbps): 1488000 pps
Packet forwarding rate (100 Mbps): 148800 pps
Packet forwarding rate (10 Mbps): 14880 pps
Jumbo frames support: Yes
Jumbo frames: 16000
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 32
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 250 W
