Design
Product colour: Green, Black
Housing material: Plastic
LED indicators: Yes
Power
USB powered: Yes
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 0 - 80%
Weight & dimensions
Height: 26 mm
Weight: 207 g
Depth: 164 mm
Width: 72 mm
System requirements
Mac operating systems supported: Yes
Windows operating systems supported: Yes
Performance
Scan interval: 15, 45, 30, 10, 40, 20, 25, 50, 35, 60 s, 55
Maximum resolution: 2048 x 1536 pixels
Packaging data
Package weight: 1.55 kg
Package depth: 85 mm
Package height: 370 mm
Package width: 195 mm
Packaging content
Cables included: KVM
Quick installation guide: Yes
Manual: Yes
Display
Built-in display: No
Ports & interfaces
USB connector type: USB Type-A
Number of computers controlled: 4
Video port type: VGA
DC-in jack: Yes
USB 2.0 ports quantity: 2
VGA (D-Sub) ports quantity: 4
Keyboard port type: USB
Console ports: USB A, VGA (D-Sub)
Console USB ports quantity: 2
Mouse port type: USB
Audio connections: No
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176200
