Power AC input frequency: 47 - 63 Hz AC input voltage: 90 - 264 V Input current: 2.25 A Total power: 120 W Power protection features: Short circuit, Over voltage, Overload Hold time: 16 ms
Operational conditions Operating temperature (T-T): -20 - 70 °C Storage temperature (T-T): -40 - 85 °C Operating relative humidity (H-H): 20 - 95% Storage relative humidity (H-H): 10 - 95%
Weight & dimensions Weight: 530 g Depth: 113.5 mm Height: 125.2 mm Width: 40 mm
Performance Mean time between failures (MTBF): 2636800 h
Packaging data Package weight: 600 g Package type: Box Package depth: 140 mm Package width: 60 mm Package height: 143 mm
Other features Output voltage note: 48V Voltage tolerance: 1%
Logistics data Country of origin: China Master (outer) case width: 310 mm Harmonized System (HS) code: 8504403090 Master (outer) cases per pallet: 20 pc(s) Master (outer) case gross weight: 13 kg Master (outer) case height: 305 mm Master (outer) case length: 310 mm
