Power AC input frequency: 47 - 63 Hz Input current: 1.45 A AC input voltage: 90 -264 V Peak power: 76.8 W Total power: 75 W Hold time: 16 ms Power protection features: Short circuit, Over voltage, Overload
Operational conditions Operating relative humidity (H-H): 0 - 90% Operating temperature (T-T): -20 - 70 °C
Weight & dimensions Width: 32 mm Weight: 430 g Depth: 102 mm Height: 125.2 mm
Performance Mean time between failures (MTBF): 486200 h
Packaging data Package width: 53 mm Package height: 147 mm Package type: Box Package weight: 500 g Package depth: 132 mm
Other features Voltage tolerance: 1% Output voltage note: 48V
Logistics data Country of origin: China Master (outer) case gross weight: 16.8 kg Master (outer) case length: 313 mm Master (outer) cases per pallet: 20 pc(s) Master (outer) case width: 282 mm Harmonized System (HS) code: 8504403090 Master (outer) case height: 393 mm
