Design Safety: EN60950-1 International Protection (IP) code: IP30 Wall mountable: Yes Rack mounting: No Product colour: Black LED indicators: Power, Link Housing material: Metal
Power Output voltage: 24 V Output current: 1 A Power consumption (typical): 3.76 W
Operational conditions Storage temperature (T-T): -40 - 85 °C Operating relative humidity (H-H): 5 - 95% Storage relative humidity (H-H): 5 - 95% Operating temperature (T-T): -40 - 75 °C
Management features Switch type: Unmanaged
Weight & dimensions Depth: 105 mm Height: 142 mm Weight: 470 g Width: 36 mm
Network Full duplex: Yes Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3x Copper ethernet cabling technology: 100BASE-TX, 10BASE-T 10G support: No Flow control support: Yes Auto MDI/MDI-X: Yes Auto-negotiation: Yes
Performance Maximum data transfer rate: 100 Mbit/s Internal memory: 1 MB
Packaging data Package width: 65 mm Package weight: 180 g Package depth: 165 mm Package type: Box Package height: 215 mm Wall mounting kit: Yes Terminal block included: Yes
