Design
Product colour: Grey, Black
Stackable: No
LED indicators: Link, Activity, Power
Rack mounting: No
Housing material: Metal
Power
Output voltage: 5 V
Power consumption (max): 6 W
Output current: 2.5 A
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 90 °C
Operating temperature (T-T): 0 - 45 °C
Weight & dimensions
Weight: 380 g
Height: 30 mm
Depth: 112 mm
Width: 96 mm
Network
10G support: No
Auto-negotiation: Yes
Full duplex: Yes
Cable types supported: Cat5
Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 100BASE-FX
Performance
Plug and Play: Yes
Maximum data transfer rate: 200 Mbit/s
Buffer size: 384 KB
Packaging data
AC adapter included: Yes
Package weight: 540 g
Rubber feet: Yes
Package depth: 250 mm
Package width: 140 mm
Package height: 55 mm
Packaging content
Quick start guide: Yes
Ports & interfaces
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Fiber optic connector: SC, ST
Basic switching RJ-45 Ethernet ports quantity: 4
Fiber ports quantity: 1
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: Taiwan
Data transmission
Packet forwarding rate (10 Mbps): 14880 pps
Packet forwarding rate (100 Mbps): 148800 pps
MAC address table: 1024 entries
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Optical fiber
Fiber ethernet cabling technology: 100BASE-FX
Transmission distance (max): 2 km
Fiber type: Multi-mode
