Technical details
Pallet height (air): 159 cm
Pallet gross length: 80 cm
Pallet gross width: 120 cm
Design
Rack mounting: No
Wall mountable: Yes
International Protection (IP) code: IP30
DIN rail mounting: Yes
Housing material: Metal
LED indicators: Power, Activity
Product colour: Black
Power
DC input voltage: 48 - 57 V
Surge protection voltage: 6 kV
Power supply included: No
Surge protection: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -30 - 65 °C
Storage temperature (T-T): -40 - 85 °C
Weight & dimensions
Height: 101 mm
Width: 65 mm
Weight: 350 g
Depth: 36 mm
Network
Full duplex: Yes
Auto-negotiation: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Half duplex: Yes
Auto MDI/MDI-X: Yes
10G support: No
Flow control support: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at, IEEE 802.3z, IEEE 802.3x
Packaging data
Terminal block included: Yes
Package height: 110 mm
Package weight: 400 g
Package type: Box
Package width: 70 mm
Package depth: 60 mm
Packaging content
Quick start guide: Yes
Ports & interfaces
SFP module slots quantity: 1
Gigabit Ethernet (copper) ports quantity: 4
Basic switching RJ-45 Ethernet ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Master (outer) case height: 360 mm
Master (outer) case width: 422 mm
Products per pallet: 24 pc(s)
Products per master (outer) case: 28 pc(s)
Master (outer) case length: 566 mm
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 13 kg
Country of origin: China
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
