Design
Product colour: Black
Stackable: No
Rack mounting: No
LED indicators: PoE, Uplink, Power, LAN
Power
AC input frequency: 50 - 60 Hz
Power protection features: Over current, Short circuit
AC input voltage: 100 - 240 V
Power consumption (typical): 65 W
Operational conditions
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 45 °C
Weight & dimensions
Weight: 800 g
Width: 90 mm
Height: 28 mm
Depth: 120 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3af, IEEE 802.3az
Cable types supported: Cat6, Cat5, Cat5e, Cat7
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
10G support: No
Packaging data
Package weight: 1.04 kg
Package width: 150 mm
Package height: 235 mm
AC adapter included: Yes
Package depth: 80 mm
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
Data transmission
Store-and-forward: Yes
Packet forwarding rate (10 Mbps): 14880 pps
Switching capacity: 10 Gbit/s
MAC address table: 2048 entries
Packet forwarding rate (1 Gbps): 1488000 pps
Jumbo frames: 9000
Packet forwarding rate (100 Mbps): 148000 pps
Jumbo frames support: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 61.6 W
Power over Ethernet (PoE) power per port: 15.4 W
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet (PoE): Yes
