Design
Product colour: Grey
LED indicators: Power, Activity, Link
Rack mounting: No
Housing material: Metal
Wall mountable: Yes
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Input current: 2.5 A
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 90 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Height: 30 mm
Weight: 380 g
Width: 96 mm
Depth: 112 mm
Network
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported: Cat5, Cat5e
Flow control support: Yes
MAC address auto-aging supported: Yes
Full duplex: Yes
Auto-negotiation: Yes
10G support: No
MAC address auto-learning supported: Yes
Packaging data
Package weight: 540 g
AC adapter included: Yes
Package depth: 250 mm
Package height: 55 mm
Package width: 140 mm
Rubber feet: Yes
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 4
Fiber optic connector: SFP
SFP module slots quantity: 1
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames: 9000
Store-and-forward: Yes
Switching capacity: 1 Gbit/s
Jumbo frames support: Yes
Packet forwarding rate (10 Mbps): 14880 pps
Packet forwarding rate (1 Gbps): 1488000 pps
Packet buffer memory: 1 MB
Packet forwarding rate (100 Mbps): 148800 pps
MAC address table: 4000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Optical fiber
Fiber ethernet cabling technology: 1000BASE‑SX, 1000BASE‑LX
Transmission distance (max): 0.55 km
