Technical details
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Pallet height (air): 148.2 cm
Master (outer) cases per pallet (air): 12 pc(s)
Design
Product colour: Black
Wall mountable: Yes
LED indicators: Activity, Link, Power
Power
Input voltage: 12 V
AC input frequency: 50/60 Hz
Power source: DC
Power supply included: Yes
Input current: 0.4 A
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 50 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 175.5 mm
Weight: 476.7 g
Height: 27.3 mm
Depth: 105.3 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3bz
MAC address auto-aging supported: Yes
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 2500BASE-T, 1000BASE-T
Flow control support: Yes
Full duplex: Yes
10G support: No
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
Half duplex: Yes
Performance
Noise level: 0 dB
Fanless: Yes
Packaging data
AC adapter included: Yes
Package weight: 614.4 g
Package width: 190 mm
Package height: 82 mm
Package depth: 115 mm
Packaging content
Quick start guide: Yes
Certificates
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC), UKCA
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 5
Logistics data
Harmonized System (HS) code: 851762
Country of origin: China
Master (outer) case height: 440 mm
Master (outer) case length: 400 mm
Master (outer) case gross weight: 33 kg
Products per master (outer) case: 50 pc(s)
Master (outer) case width: 605 mm
Data transmission
Jumbo frames: 15000
Jumbo frames support: Yes
Packet buffer memory: 4 MB
Forwarding rate: 18.6 Mpps
Switching capacity: 25 Gbit/s
MAC address table: 8000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
