Design
Rack mounting: Yes
Reset button: Yes
LED indicators: PoE, Power, Link
Housing material: Metal
Product colour: Grey
Power
Power consumption (max): 473.7 W
AC input frequency: 50 - 60 Hz
Input current: 6 A
AC input voltage: 100 - 240 V
Security
Authentication type: RADIUS
Authentication: Guest VLAN, Web-based authentication
SSH/SSL support: Yes
Queue scheduling algorithms: Priority queuing (PQ), Weighted Round Robin (WRR)
Password protection: Yes
DHCP features: DHCP server, DHCP snooping, DHCP relay
IGMP proxy: Yes
Security algorithms: SNMPv3
IGMP snooping: Yes
Access Control List (ACL): Yes
DoS attack prevention: Yes
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Management features
ARP inspection: Yes
Quality of Service (QoS) support: Yes
Configuring Location Settings (CLI): Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Width: 440 mm
Weight: 4.52 kg
Depth: 330 mm
Height: 44.5 mm
Network
Virtual LAN features: Voice VLAN, MAC address-based VLAN, VLAN Identifier ( VLAN ID), Port-based VLAN, Tagged VLAN, Protocol-based VLAN
Rate limiting: Yes
Number of VLANs: 4096
10G support: Yes
VLAN support: Yes
Port mirroring: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ag, IEEE 802.3ah, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1x, IEEE 802.1w, IEEE 802.3az, IEEE 802.1v, IEEE 802.3, IEEE 802.1p
Link aggregation: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Network virtualization technologies: Q-in-Q tunneling
QinQ implementation: Selective QinQ
Performance
Internal memory: 32 MB
Telnet: Yes
Firmware upgradeable: Yes
Packaging data
Package type: Box
Package height: 80 mm
Package width: 596 mm
Rubber feet: Yes
Package depth: 390 mm
Package weight: 6 kg
Packaging content
Quick start guide: Yes
Rack mount kit: Yes
Cables included: AC
Certification: CE
Certificates
Compliance certificates: RoHS
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
IPv4 & IPv6 features: IPv6 Telnet
Ports & interfaces
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports quantity: 48
Console port: RJ-45
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 48
SFP+ module slots quantity: 4
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Data transmission
Forwarding rate: 130.944 Mpps
Packet buffer memory: 512 MB
MAC address table: 16000 entries
Jumbo frames: 12000
Store-and-forward: Yes
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 48
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 400 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: v1/v2
