Design
Wall mountable: Yes
International Protection (IP) code: IP30
Housing material: Metal
DIN rail mounting: Yes
Product colour: Black
LED indicators: Activity, Power, Link
Power
Power protection features: Reverse polarity, Overload
Input voltage: 12 - 55 V
Power consumption (typical): 6 W
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Depth: 105 mm
Height: 38 mm
Width: 40 mm
Weight: 720 g
Network
Auto-negotiation: Yes
Auto MDI/MDI-X: Yes
Full duplex: Yes
Flow control support: Yes
Networking standards: IEEE 802.3at, IEEE 802.3af, IEEE 802.3, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3u
Packaging data
Package width: 215 mm
Package depth: 165 mm
Package weight: 120 g
Package height: 65 mm
Packaging content
Quick start guide: Yes
Ports & interfaces
Combo SFP ports quantity: 1
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 4
SFP module slots quantity: 1
Other features
Terminal block port: Yes
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: Taiwan
Data transmission
MAC address table: 1024 entries
Store-and-forward: Yes
Packet forwarding rate (10 Mbps): 14880 pps
Switching capacity: 12 Gbit/s
Packet forwarding rate (1 Gbps): 1488000 pps
Packet forwarding rate (100 Mbps): 148000 pps
Jumbo frames: 10000
Packet buffer memory: 1 MB
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 126 W
Power over Ethernet plus (PoE+) ports quantity: 4
Power over Ethernet (PoE): Yes
