Design
Product colour: Black
Housing material: Metal
Rack mounting: Yes
LED indicators: Activity, PoE, LAN, Power
Stackable: No
Power
AC input frequency: 50 - 60 Hz
Power protection features: Over current, Short circuit
Power supply included: Yes
AC input voltage: 100 - 240 V
Power consumption (typical): 65 W
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 45 °C
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Weight: 800 g
Height: 160 mm
Depth: 44 mm
Width: 122 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3af, IEEE 802.3, IEEE 802.3u, IEEE 802.3at
Full duplex: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
10G support: No
Flow control support: Yes
Performance
Buffer size: 64 KB
Plug and Play: Yes
Packaging data
Package weight: 1.1 kg
Package type: Box
Package depth: 80 mm
Package height: 235 mm
Package width: 145 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity: 8
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 1.6 Gbit/s
Packet forwarding rate (10 Mbps): 14880 pps
Packet forwarding rate (100 Mbps): 148000 pps
Store-and-forward: Yes
Forwarding rate: 0.1488 Mpps
MAC address table: 1024 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 65 W
Power over Ethernet plus (PoE+) ports quantity: 4
Multicast features
Multicast MAC address table: 1000 entries
