Design
DIN rail mounting: Yes
Product colour: Black
International Protection (IP) code: IP30
LED indicators: PoE, Power
Wall mountable: Yes
Safety: EN60950-1, EN60068
Housing material: Metal
Power
DC input voltage: 48 - 56 V
Redundant power supply (RPS) support: Yes
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 95%
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 105 mm
Depth: 36.2 mm
Weight: 525 g
Height: 142 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.3z, IEEE 802.3u, IEEE 802.3af, IEEE 802.3, IEEE 802.3ab, IEEE 802.3x
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Full duplex: Yes
Performance
Plug and Play: Yes
Mean time between failures (MTBF): 510304 h
Packaging data
Terminal block included: Yes
Wall mounting kit: Yes
Package weight: 730 g
Package width: 165 mm
Package type: Box
Package height: 215 mm
Package depth: 65 mm
Packaging content
Manual: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Other features
Terminal block port: Yes
Logistics data
Master (outer) case length: 240 mm
Master (outer) case width: 350 mm
Master (outer) case height: 570 mm
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
Products per master (outer) case: 16 pc(s)
Master (outer) case gross weight: 12.6 kg
Data transmission
Store-and-forward: Yes
Jumbo frames: 9000
MAC address table: 8000 entries
Switching capacity: 16 Gbit/s
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) voltage range: 48 - 56 V
Power over Ethernet plus (PoE+) ports quantity: 8
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 200 W
Power over Ethernet (PoE) power per port: 36 W
