Design
Stackable: No
Housing material: Metal
Product colour: Black
LED indicators: Power, Activity, LAN
Power
Power protection features: Over current, Short circuit
Input voltage: 52 V
Input current: 2.5 A
Power consumption (typical): 10 W
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -20 - 70 °C
Weight & dimensions
Depth: 30 mm
Width: 86 mm
Weight: 450 g
Height: 176 mm
Network
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3af
Full duplex: Yes
10G support: No
Performance
Buffer size: 8 KB
Internal memory: 1 MB
Mean time between failures (MTBF): 30000 h
Packaging data
Package height: 290 mm
Package width: 230 mm
AC adapter included: Yes
Package depth: 60 mm
Package weight: 950 g
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Data transmission
MAC address table: 8000 entries
Jumbo frames: 9126
Jumbo frames support: Yes
Switching capacity: 16 Gbit/s
Store-and-forward: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 120 W
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
