Design
Rack mounting: Yes
Product colour: Grey
LED indicators: Activity, Power, PoE
Power
Power consumption (typical): 250 W
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Input current: 5 A
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 10 - 90%
Weight & dimensions
Width: 280 mm
Height: 44 mm
Depth: 185 mm
Weight: 2 kg
Network
Copper ethernet cabling technology: 1000BASE-TX, 10BASE-T, 100BASE-TX
Cable types supported: Cat5, Cat5e, Cat7, Cat6
Networking standards: IEEE 802.3u, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3at
Performance
Buffer size: 128 KB
Packaging data
Package height: 82 mm
Package depth: 230 mm
Package weight: 2.26 kg
Package type: Box
Package width: 371 mm
Packaging content
Cables included: AC
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: Taiwan
Data transmission
Packet forwarding rate (10 Mbps): 14880 pps
Packet forwarding rate (1 Gbps): 1488000 pps
Switching capacity: 16 Gbit/s
Packet forwarding rate (100 Mbps): 148000 pps
MAC address table: 8192 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 9000
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 8
Total Power over Ethernet (PoE) budget: 240 W
Power over Ethernet (PoE): Yes
