Design
LED indicators: Activity, Link, Power
Stackable: No
Wall mountable: Yes
Rack mounting: No
Product colour: Red, Black
Power
Power consumption (typical): 3 W
Input current: 1 A
Power supply included: No
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 10 - 90%
Management features
Switch type: Unmanaged
Weight & dimensions
Height: 27 mm
Width: 149.5 mm
Weight: 135 g
Depth: 89 mm
Network
Copper ethernet cabling technology: 10BASE-T, 1000BASE-T, 100BASE-TX
Auto-negotiation: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x, IEEE 802.3u
10G support: No
Flow control support: Yes
Full duplex: Yes
Auto MDI/MDI-X: Yes
Performance
Flash memory: 1024 MB
Packaging data
Package weight: 300 g
Package width: 142 mm
Package depth: 92 mm
Package height: 92 mm
AC adapter included: Yes
Package type: Box
Packaging content
Quick start guide: Yes
Ports & interfaces
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Data transmission
Switching capacity: 16 Gbit/s
Jumbo frames support: Yes
Packet forwarding rate (100 Mbps): 148000 pps
Packet forwarding rate (1 Gbps): 1488000 pps
Jumbo frames: 9000
MAC address table: 8192 entries
Store-and-forward: Yes
Packet forwarding rate (10 Mbps): 14880 pps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
