Technical details
Pallet height (air): 11.5 cm
Pallet gross width: 120 cm
Pallet gross length: 110 cm
Design
Push button: Yes
Cascadable: Yes
Hot keys: Yes
Product colour: Black
Housing material: Metal
Rack mounting: Yes
Rack capacity: 1U
LED indicators: Power
Power
Power source: DC
External power adapter: Yes
Input voltage: 9 V
Input current: 1 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 90%
Storage temperature (T-T): -10 - 70 °C
Operating relative humidity (H-H): 0 - 85%
Weight & dimensions
Weight: 1.84 kg
Depth: 165 mm
Height: 44.5 mm
Width: 410 mm
System requirements
Windows operating systems supported: Windows Vista Ultimate x64, Windows 7 Enterprise, Windows Vista Business, Windows Vista Ultimate, Windows 7 Ultimate x64, Windows Vista, Windows 7 x64, Windows Vista Enterprise, Windows 7 Professional, Windows 7, Windows XP Professional x64, Windows Vista Business x64, Windows XP Professional, Windows XP, Windows Vista Home Basic, Windows ME, Windows 7 Home Basic x64, Windows 98SE, Windows 7 Home Premium, Windows 7 Starter, Windows 95, Windows Vista Enterprise x64, Windows Vista Home Basic x64, Windows 7 Professional x64, Windows Vista Home Premium, Windows XP Home, Windows 7 Starter x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 98, Windows Vista x64, Windows 7 Home Basic, Windows 7 Ultimate, Windows 2000, Windows Vista Home Premium x64, Windows XP Home x64
Mac operating systems supported: Yes
Linux operating systems supported: Yes
Performance
Auto scan delay (min): 10 s
Maximum resolution: 2048 x 1536 pixels
Daisy chain: Yes
Auto scan delay (max): 95 s
Scan interval: 20, 15, 45, 35, 60 s, 30, 10, 40, 50, 70, 55, 25, 80, 90 s
Maximum operating distance: 30 m
Packaging data
Package width: 567 mm
Package weight: 2.88 kg
Package type: Box
Package depth: 245 mm
Package height: 106 mm
Packaging content
AC adapter included: Yes
Manual: Yes
Display
On Screen Display (OSD): Yes
Built-in display: No
Ports & interfaces
Video port type: VGA
PS/2 ports quantity: 2
Mouse port type: USB, PS/2
Console ports: PS/2, VGA (D-Sub), USB A
Keyboard port type: USB, PS/2
Number of computers controlled: 8
VGA (D-Sub) ports quantity: 8
Console USB ports quantity: 2
DC-in jack: Yes
Logistics data
Master (outer) case width: 585 mm
Country of origin: Taiwan
Master (outer) case length: 270 mm
Master (outer) cases per pallet (air): 24 pc(s)
Master (outer) case gross weight: 15.2 kg
Products per master (outer) case: 5 pc(s)
Master (outer) case height: 545 mm
Sustainability
Sustainability compliance: Yes
Compliance certificates: CE, Federal Communications Commission (FCC), UKCA, WEEE
