Features
5 GHz: Yes
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
MIMO: Yes
Maximum data transfer rate: 1200 Mbit/s
Frequency band: 2.4 ~ 2.4835, 5.15 ~ 5.35, 5.46 ~ 5.72, 5.725~ 5.825 GHz
2.4 GHz: Yes
Networking standards: IEEE 802.3, IEEE 802.11a, IEEE 802.3at, IEEE 802.3u, IEEE 802.11ac, IEEE 802.3x, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3az, IEEE 802.11i, IEEE 802.11b
Modulation: 256-QAM, QPSK, DQPSK, 128-QAM, 64-QAM, CCK, OFDM, DSSS, 16-QAM, BPSK, DBPSK
Quality of Service (QoS) support: Yes
Automatic channel selection: Yes
Maximum data transfer rate (2.4 GHz): 300 Mbit/s
Operating modes: Access Point (AP),Gateway,Repeater,WISP
Number of users: 128 user(s)
Wi-Fi Multimedia (WMM)/(WME): Yes
Virtual LAN features: Tagged VLAN
MIMO type: Multi User MIMO
Maximum data transfer rate (5 GHz): 867 Mbit/s
Design
Product colour: White
Reset button: Yes
Internal: No
LED indicators: Power, Status
Placement: Ceiling
Power
Power over Ethernet (PoE): Yes
Power consumption (typical): 30 W
Security
Security algorithms: 128-bit WEP, 64-bit WEP, WPA2, WPA, TKIP, 128-bit AES, WPA2-PSK
Service Set Identifier (SSID) features: SSID broadcast on/off
Number of SSID supported: 8
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -30 - 55 °C
Storage relative humidity (H-H): 5 - 95%
Management features
Firmware upgradeable: Yes
Web-based management: Yes
Switch type: Managed
Weight & dimensions
Weight: 520 g
Width: 198 mm
Height: 198 mm
Depth: 28 mm
Packaging data
Package width: 235 mm
Package height: 243 mm
Package type: Box
Package depth: 81 mm
Package weight: 830 g
CD quick installation guide: Yes
CD manual: Yes
Packaging content
Quick start guide: Yes
Mounting kit: Yes
Cables included: LAN (RJ-45)
Ports & interfaces
WAN connection: Ethernet (RJ-45)
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Antenna
Antenna gain level (max): 5 dBi
Antenna features: Integrated antenna
Antennas quantity: 4
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
Master (outer) case width: 435 mm
Products per master (outer) case: 20 pc(s)
Master (outer) case length: 491 mm
Master (outer) case height: 515 mm
Master (outer) case gross weight: 18 kg
